Autonics - Automation Control - HMI LP-S044 Series
4.4-Inch Monochrome Widescreen Logic Panels
The LP-S044 series logic panels are all-in-one devices featuring functions of HMI, PLC, and I/O modules. The units can control and monitor various devices connected via communication ports. 16 input and 16 output contact points are provided. Logic programming memory supports up to 8,000 steps with support for 28 basic commands and 220 application commands. The logic panels can display up to 400 characters per screen, and users may save up to 500 screen pages. Various fonts including bitmap fonts and user selected fonts are supported. Printer and bar code readers are also supported for printing alarm history or reading bar codes.
- Compact structure : Reducing cost, space saving and easy operation through PLC+HMI+Input/ output integration
- Improved compatibility with logic : 8000-step program capacity (the average processing speed 6 to 7μs/step) basic command 28, application command 220
- Wide device range : Peripheral device 10K word, data device 10K word, and other various devices
- Sufﬁ cient external I/O : Input 16-point, output 16-point (basic)
- Various expansion function : External interrupt, 16-key input, 7 Seg. time-sharing display and synchronous communication output.
- Easy software upgrade available on website
(1) LP ﬁrmware ﬁle
(2) GP Editor (drawing program)
(3) Smart Studio (logic program)
(4) Additional protocol
- Displays max. 400 characters
- Enables to save max. 500 pages of user screen
- Different devices monitoring function : allows to monitor and control the variables of additionally connected controllers (such as PLC) with external communication port
- Supports multilingual : Supports for Korean, Japanese, English, Chinese, Russian, Vietnamese and Portuguese. Additional languages will be available by ﬁ rmware.
- Supports multi-font : It provides various bitmap and user-selected fonts.
- Various multi-communication ports : Both RS232 2 port and RS232/RS422 compound port are provided.
- Device monitoring function : It enables to monitor LP device and connected controller devices by LP without graphic design data.
- Printer and barcode reader connection : It enables to print alarm history connecting a printer and read barcode connecting a barcode reader.
- Controlling automatic PCB transfer in Soldering machine
